New Energy Powertrain Solutions for Commercial Vehicle Hybrids
Off-road new energy power system solutions
Pure electric new energy power system solutions
in light weight
Light weight and small size of the system
Light weight and small size of the system
high power density
Flat wire motor, high power density, high efficiency, good NVH performance
Flat wire motor, high power density, high efficiency, good NVH performance
low cost
High-speed motor solution, low system cost
High-speed motor solution, low system cost
|
model
|
YCET280-0342
|
|---|---|
|
motor model
|
TZ330XS280
|
|
motor type
|
Permanent magnet synchronous motor (flat wire)
|
|
Voltage platform (VDC)
|
600
|
|
Motor rating/peak power (kW)
|
280/430
|
|
Motor rated/peak torque (N·m)
|
440/800
|
|
Motor rated/peak speed (r/min)
|
6077/10000
|
|
speed changing box
|
Fourth gear/sixth gear
|
|
Maximum output torque of wheel end (N·m)
|
20700 (fourth gear box)
|
|
speed ratio
|
8.625/3.824/1.927/1.00 (fourth gear box) 3.011 (reducer)
|
